Introduction to the Official CNA7 Measurement Software
The Konzolius CNA 7 measurement software is divided into two versions: the professional edition and the enterprise edition (with all modules).
— Professional Edition: Hard Testing + CAD
— Enterprise Edition: Hard testing + CAD + Pipe fittings
(1) Key features of the Professional Edition of the Konzolius CNA7 measurement software:
1. The new interface of the CNA7 measurement software makes the measurement process faster, easier and more effortless! The newly designed interface and toolbar have significantly enhanced the daily working efficiency and brought more production benefits to you.
2. Geometric and surface measurement tasks can be completed within the same user interface!
3. The software's geometric algorithms have been certified by the authoritative PTB.
4. In the same measurement window, multiple coordinate systems can be displayed, along with a wealth of graphical fitting options.
5. Multi-view display for workpiece measurement window, with graphical view zooming and rotation, and optional 3D solid and wireframe display.
6. Full-scale measurement and geometric tolerances.
7. Completely new intelligent construction function.
8. Digital reverse engineering of workpieces.
9. Mouse rotation/panning and zooming/View grid lines/Adjustable lighting.
10. Supports the "Go mode" for manual measurement sequences, significantly enhancing the feature measurement function with the automatic view replay of the Go mode.
11. The file/serial port data is exported to SPC and Excel spreadsheets.
12. The measurement results can be exported as Microsoft Excel spreadsheets and in HTML format, and multiple predefined templates are available for selection.
13. A fully functional graphical measurement report generator that supports user customization.
14. It has a surface feature measurement module, capable of measuring surface points, surface edges and surface blocks. It can be used in manual/automatic CMM measuring machines and on measuring arms for measuring complex-shaped workpieces.
15. By using CAD nominal data to measure the workpiece, one can search and capture/view layers/CAD entity control/CAD conversion/mouse rotation/pitching and zooming/ view grid lines/ adjustable lighting and shadows/adjusting the CAD search range and error rate.
16. 3D best-fit for workpieces, best-fit for multiple bodies, RPS reference point system fitting.
17. Graphical display of surface deviation.
18. Support the import of common 3D CAD formats such as IGES and STEP.
19. Abundant CAD detection methods.
20. The surface errors are represented by means such as labels, vectors, or color coding.
21. CAD 3D solid model display / wireframe display view.
(2) Main features of the enterprise version of the Konzolius CNA7 measurement software:
1. It integrates the CNA 7 standard version and the pipe fitting measurement system, providing a perfect geometric and pipe fitting measurement experience. All measurement operations such as geometry, pipes, and pipelines can be easily completed in the same user interface.
2. Use the nominal data of pipe fittings to conduct high-speed detection of pipe fitting fixtures.
3. Automatically generate 3D pipe fitting graphics using nominal data.
4. Automatically generate the measurement sequence for pipe fittings.
5. Read the nominal data directly from the CAD.
6. Conversion of nominal data from automotive industry coordinates to pipe fitting coordinates.
7. Input of XYZ/YBC coordinate data and conversion from XYZ to YBC.
8. Use the nominal model to inspect pipe fittings and provide a wide range of fitting options for the starting points, intersection points and supports.
9. Customizable graphical measurement reports and an overview of the tested pipe components.
10. Support various measurements such as the assembly position of the support bracket or pipe fitting.
11. Pipe fitting coordinate data / Automotive industry data / Aviation industry data input.
12. Multiple interfaces for connecting the bending machine via serial port and network have been provided.
